Specifications
Electrical parameters
| Light source | LED |
| Power voltage | AC 220–240 V / 50–60 Hz |
| Connection method | terminal block (supplied without cable) |
| Ballast part | electronic driver with integrated surge protection |
| Possibility of regulation | without regulation (not labeled), DALI (DALI), Night dimming (A) |
| Emergency module | NO |
Light parameters
| Optical system | diffuser (DPO) |
| Light distribution | direct |
| Colour rendering index | Ra > 70, Ra > 80 |
| Colour temperature | 2 700 K, 3 000 K, 4 000 K |
| Service life | > 100 000 hod. (L90B10) |
Construction
| Luminaire body | powder-coated steel sheet |
| Colour | RAL 7016, other RAL (on request), exterior finish (V) |
| Surface type | gloss |
| Luminaire cover | glass diffuser, opal (DPO) |
Safety
| Protection class | I, II |
| Maximum ambient temperature | -30 / +40 °C |
| Ingress protection | IP 65 |
| impact protection | IK 10 |
Mounting
| Method | surface mounted, corner mounted |
| Recommended height | from 2 to 6 m |
Accessories
| Clips | NO |
| Suspension accessories | corner holder (to order), mounted holder (to order) |
| Notes | luminaire is equipped with security screws are for protection against theft |
| Use | garages, jails, passages, pedestrian underpasses |
Luminaire is equipped with security screws are for protection against theft.
